Item Condition: New
Used on the following models:
FreeMotion
3000 XLS Treadmill - VFMTL11060
3500 XLS Treadmill - VFMTL12060
Nordic-Track®
Professional Series 3500 - NTL349050
Professional Series 4000 - NTL399050
Motor housing diameter measures 115mm (4.527"). Removable, heavy (8.4 lb.) steel flywheel mounted onto tapered motor shaft by means of retention screw. Flywheel measures 172mm (6.772") dia. x 36mm thick. Flywheel has 2.1" O.D. ten-groove pulley for serpentine belt.
SPECIFICATIONS
Power 3.5 HP (2611 W)
Voltage 150 VDC
Amperage 20.1 Amps
Speed 4500 RPM @ 150 VDC, No Load
Rotation Reversible
Enclosure OFC
Duty Treadmill
Mount Two 7mm Holes in Housing on 3" Centers
Shaft 17mm dia. x 35mm overall length, Tapers from 17mm to 16mm in 24mm, End tapped 3/8"-16
Size 12-1/2" x 6-3/4" O.D.
Shpg. 34 lbs.
- Part Name: MTR,DRIVE,ARPS,12MPH,SHORT
- Compatible Models Below.
- If you are uncomfortable with diagnosing and treating your machine with the RIGHT replacement parts we can recommend a fitness technician in your area via zip code
