Condition New
3.75" STROKE 900LB PULL 120 VAC LINEAR ACTUATOR ICON HEALTH AND FITNESS 299425
3.75" STROKE 900LB PULL 120 VAC LINEAR ACTUATOR
New, Icon Health & Fitness model# 299425 120V 900LB PULL linear actuator. Power extend and power retract. Rated to pull up to 900 pounds, extend under no load. Shaded pole motor with open construction and external fan, thermally protected. Hall-effect sensor connected to internal gearing allows for use with position-sensing circuits.
SPECIFICATIONS
3.75" STROKE 900LB PULL 120 VAC LINEAR ACTUATOR ICON HEALTH AND FITNESS 299425
3.75" STROKE 900LB PULL 120 VAC LINEAR ACTUATOR
New, Icon Health & Fitness model# 299425 120V 900LB PULL linear actuator. Power extend and power retract. Rated to pull up to 900 pounds, extend under no load. Shaded pole motor with open construction and external fan, thermally protected. Hall-effect sensor connected to internal gearing allows for use with position-sensing circuits.
SPECIFICATIONS
- Stroke 3-3/4"
- Voltage 120 VAC, 60 Hz
- Amperage 1.5 Amps
- Push/Pull Rating
- Dynamic Rated to Pull 900 lb.
- Extension Speed
- No Load 0.092in./sec.
- RPM 27 RPM
- Thread 3/4"-6 Acme Thread
- Limit Switches No Limit Switches
- Direction Reversible
- Duty Intermittent
- Retracted length 6-7/8"
- Pin Holes 3/8"
- Size 7-3/4" x 4-1/4" x 3-1/8"
- Shpg. 6 lb.
