Condition Used
Blue Resistance motor, black connector
The white cam may have to be adjusted during install because each machine may have minor differences.
The phillips center screw in the white cam can be loosened to adjust the cam position.
Servo Motor Where Used:
Sole UE35 Gear (Resistance) Motor. PRE 2008 Only.
Manufacturers part # 022170
Sole E25 Gear (Resistance) Motor (2007 - 2008)
Sole E35 Gear (Resistance) Motor (2007 - 2008)
Sole E55 Gear (Resistance) Motor (2006 - 2008)
Sole E75 Gear (Resistance) Motor
Sole E95 Gear (Resistance) Motor (2007 & 2008)
