Item Description
Condition Used
Nautilus Residential NT-1800, NT-1810, NT-1820 and NT-1830 Premier Half Cage | Smith Machine w Lat Pulldown Home Gym Strength System
1. NT-1800: Premier Half Cage (Base Unit)
This is the main white/silver frame you use for squats and bench presses.Material: Heavy-duty 11-gauge steel with a tensile strength of 47,000 psi.
Structure: 3" x 3" upright posts.
Safety Features: Includes long adjustable safety spotter arms and J-hooks.
Weight Capacity: Rated for 600 lbs on the rack hooks.
Dimensions: Approximately 48" W x 50" D x 82" H (Base frame only).
2. NT-1810: Smith Machine Attachment
This adds the "guided" barbell system to the front of the half cage.Bar Weight: Unlike commercial Smith machines, this bar is not counter-weighted. The bar itself weighs approximately 45 lbs (starting resistance).
Angle: Features a 7-degree slant to mimic the natural path of motion for squats and presses.
Weight Capacity: Rated for a maximum load of 800 lbs (plates).
User Limit: 350 lbs body weight.
3. NT-1820: Lat Tower / High-Low Pulley
This is the tall center tower that sits at the back of the cage.Resistance: Plate-loaded + Weight stacks
Pulley Ratio: 1:1 (If you put 100 lbs on, you lift 100 lbs).
Function: Includes a High Pulley (Lat Pulldowns) and a Low Pulley (Seated Rows/Curls).
Weight Capacity: Rated for 300 lbs of plates.
4. NT-1830: Pec Attachment (Pec Deck)
The pivoting arms for chest flies that bolt onto the NT-1820 Lat Tower.Function: Isolateral movement (arms move independently).
Design: Based on Nautilus's commercial "cam" technology to provide consistent tension throughout the fly.
Weight Capacity: Rated for 300 lbs (integrated into the Lat Tower cable system).
Pads: Rectangular high-density foam pads for the forearms.
Adjustments: Includes a "Pec Back Pad" that attaches to the center upright for support.
Summary of Full System Dimensions
When you have all four components bolted together, the machine takes up a significant footprint:Height: ~82.5 inches (Check your ceiling clearance!)
Width: ~89 inches (Width of the Smith bar and storage pegs).
Depth: ~67 to 75 inches (Distance from the front of the Smith bar to the back of the Pec attachment).
Total Weight: Fully assembled without plates, the unit weighs approximately 450–500 lbs.
