Item Condition: New

NordicTrack Treadmill Dc Drive Motor 3 HP M-193022 - fitnesspartsrepair
NordicTrack Treadmill Dc Drive Motor 3 HP M-193022 - fitnesspartsrepair

NordicTrack Treadmill Dc Drive Motor 3 HP 195651 or M-193022 339949

  • $402.99
Catalog Number: I3-Y0KC-QVJH

"Have fitness repair parts to Sell?"
Use our wizard and list them for FREE on our exchange

OR

Sell them lot to us using this form


Secure Checkout With
secure trust badge
IMPORTANT: Want to see a complete parts list and/or diagram of your fitness equipment?

If so, have your model/serial number from your frame ready and click here.

Item Description



Item Condition: New

3 HP TREADMILL MOTOR
New, Icon Health and Fitness model# M-193022 permanent magnet motor with brushes. Built for use in treadmills, ideal for use with speed controller (sold separately). Would also make an excellent DC generator. Internal, normally closed bimetallic switch signals thermal overload. Two 7mm holes in motor housing for self-tapping screws.
Motor housing diameter measures 115mm (4.527"). Removable, heavy (9.0 lb.) steel flywheel threaded onto motor shaft measures 7" dia. x 1-3/8" thick. Flywheel has 2.10" O.D. ten-groove pulley for serpentine belt, doubles as cooling fan.

SPECIFICATIONS
Power 3.0 HP
Voltage 130 VDC
Amperage 22.1 Amps
Speed 2975 RPM (Nameplate)
4465 RPM @ 130 VDC, No Load
Rotation Reversible
Enclosure OFC
Duty Treadmill
Mount Two 7mm Holes in Housing on 3" Centers
Shaft 17mm dia. x 54mm overall length w/ 1/2"-13 x 15mm long LH threaded end
Rear Shaft 16mm dia. x 26mm overall length
Size 12-3/8" x 7" O.D.
Shpg. 34 lbs.

3 HP ICON HEALTH AND FITNESS TREADMILL MOTOR M-193022



  • 3 HP ICON HEALTH AND FITNESS TREADMILL MOTOR M-193022
  • 90 Day Warranty
  • Save compared to Manufacturer
  • Motor Specs Below.
  • Please allow 2 business days for packing and shipment.

Compatible Models

NordicTrack®

E3700 - GNTL228040
E3700 - NETL95130
E3700 - NETL95131
E3700 - NETL95133
E3700 - NETL95134
E3700 - NETL95135
E4400 - 831.293290
E4400 - 831.293291
E4400 - NTL24820
E4400 - NTL24821

Proform

1800 Interactive Trainer - DTL21140
