Item Condition: New
Hydra Fitness Exchange RPM Reed Speed Sensor – Barrel Style with Snap-In Frame Mount Cardio Equipment
"Have fitness repair parts to Sell?"
Use our wizard and list them for FREE on our exchange
OR
Sell them lot to us using this form
If so, have your model/serial number from your frame ready and click here.
Item Description
Condition New
RPM Reed Speed Sensor – Barrel Style with Snap-In Frame Mount
2-Pin Connector – 80mm (3.15") Length – Fitness Equipment Replacement
This barrel-style RPM reed speed sensor features a snap-in frame mount design for quick installation and reliable positioning. Built for accurate motion detection, it is ideal for restoring speed and RPM tracking on a wide range of fitness equipment.
Key Features
- Barrel-Style Sensor: Cylindrical probe for precise magnetic RPM detection
- 2-Pin Connector: Standard plug for broad compatibility
- Snap-In Frame Mount: Integrated mounting tab for secure, tool-free installation
- Adjustable Positioning: Allows proper alignment with magnet for accurate readings
- Compact & Durable: Designed for long-term use in demanding environments
- Easy Replacement: Direct swap for worn or faulty sensors
Dimensions
- Length of sensing probe (stick area): 35mm (1.38")
- Total length: 80mm (3.15")
Mounting Design (Important)
- Snap-in frame mount bracket included
- Designed for through-hole or panel mounting applications
- Sensor barrel positions directly toward magnet pickup point
- Ensures stable alignment while allowing easy servicing
Applications
Commonly used in:
- Treadmills – monitors belt speed via front roller or motor pulley
- Ellipticals – tracks flywheel rotation and stride speed
- Exercise bikes (upright & recumbent) – measures pedal RPM/cadence
- Cardio equipment with magnetic speed sensing systems
Why Choose This Speed Sensor?
The snap-in mounting design makes installation fast and secure while maintaining accurate sensor alignment. Ideal for maintenance and repair, it restores proper speed feedback and smooth operation across many types of fitness equipment.
Compatibility
- Compatible with many fitness equipment brands including:
- NordicTrack®
- ProForm®
- Horizon®
- Schwinn®
- Bowflex®
- True Fitness ®
- Octane Fitness ®
- XTERRA®
- Sunny Health & Fitness®
- Used across treadmills, ellipticals, and stationary bikes
- Fit depends on connector type, mounting style, and dimensions
⚠️ Fitment Note (Important)
To ensure proper fit, verify the following before ordering:
- Connector type: Must match your existing 2-pin plug
- Mounting style: Snap-in frame mount / bracket style
- Sensor length: 80mm total / 35mm probe
- Alignment: Must line up with magnet (typically 2–5mm gap)
Do not rely on brand alone—many machines use similar sensors with slight variations.
