Item Condition: New
Matrix Fitness Elliptical Heart Rate Pulse Receiver Circuit Board 0000083655 003274-A #500EX-JHT
"Have fitness repair parts to Sell?"
Use our wizard and list them for FREE on our exchange
OR
Sell them lot to us using this form
If so, have your model/serial number from your frame ready and click here.
Item Description
Condition New
8500-J02
Used on the following models:
Matrix Fitness
Ascent - A5x-07 - 2006-2008 (EP72)
Ascent Trainer - A3x-01-G4 - 2009 - Silver (Before SN EP99101000580)
Ascent Trainer - A3x-01-G4 - Silver (After SN EP99101000580)
E3xc Elliptical - EP301 (Before S/N EP301100802081)
E5-G1 2004 (MEP23)
E5x-05
E5x-06 Rev 2007
Hybrid Cycle - H3x-01-G4 - 2009 (CB87)
I5x-G3 (EP76)
MX-E5xc - E5xc-06-G3 - 2006-2008 - Silver (After SN EP74080204567)
Premium Series - U5x-02-G4 - 2009 - Silver (CB75 & EP90)
R3x-01-G4 - 2009 (RB303)
R5-G1 (MRB50)
R5x-05-G2 (MRB50B)
R5x-06-G3 (RB83)
RS-1US
T1x - T1x-02-G4 - 2009-2010 (FTM507B, CTM507)
T1x - T1x-03 - 2012 (FTM507D, CTM507C)
T1x - T1x-LS - 2012
T1x - T1x-LS-G4 - 2010 (FTM514, CTM514)
T1xe - 2012 (FTM507D, CTM510C)
T1xe - T1xe-LS - 2012
T1xe - T1xe-LS-G4 - 2010 (FTM514, CTM515)
T3x - 2012 (FTM509D, CTM509C)
T3x - T3x-02-G4 - 2009 (FTM509B, CTM509)
T3x - T3x-05-G2 - 110V 2005 (MTM68BMXT3X)
T3x - T3x-05-G2 - 220V 2005 (MTM68BMXT3X)
T3x - T3x-06-G3-110 - 2006-2008 (TM94)
T3x - T3x-06-G3-220 - 2006-2008 (TM94)
T3xe - 2012 (FTM509D, CTM510C)
T3xe - T3xe-02-G4 - 2009-2010 (FTM509B, CTM510)
T3xi - T3xi-06-G3-220 - 2006-2008 (TM94B)
T3xi - T3xi-08-G3 - 2006-2008 (TM504)
T5 - T5-G1 - 2002-2004 (MTM65)
T5x - 2012 (FTM501E, CTM501D)
T5x - T5x-04-G4 - 2009-2010 (FTM501C, CTM501C)
T5x - T5x-05-G2 - 2005 (MTM65C)
T5x - T5x-06-G3-110 - 2006-2008 (TM65D)
T5x - T5x-06-G3-220 - 2006-2008 (TM65D)
T7xe - T7xe-02-G4 - 2009-2010 (FTM501C, CTM503D)
T7xe - T7xe-03 - 2013 (FTM501E, CTM520, CTM520B)
T7xi - T7xi-02-G4 - 2009-2010 (FTM501C, CTM502C)
U3x - U3x-01-G4 - 2009 - Silver (CB86)
U5x - U5x-05-G2 - 2005 - Silver (MCB32B)
U5x - U5x-06-G3 - 2006-2008 - Silver (CB65)
Updated List 2025
A3x-01-G4 | EP99 | 2009
E3x-01-G4 | EP301 | 2009
E5-G1 | MEP23 | 2002-2004
E5x-05-G2 | MEP000 | MEP23B | 2005
E5x-06-G3 | EP23C | 2006-2008
E5xc-06-G3 | MEP001 | EP74 | 2006-2008
H3x-01-G4 | CB87 | 2009
R3x-01-G4 | RB303 | 2009
R5-G1 | MRB50 | 2002-2004
R5x-05-G2 | MRB50B | 2005
R5x-06-G3 | RB83 | 2006-2008
S5x-G3 | CS08 | 2006-2008
T1xe-LS-G4 | FTM514 | CTM515 | 2009
T1x-LS-G4 | FTM514 | CTM514 | 2010
T3x-02-G4 | FTM509B | CTM509 | 2009
T3x-05-G2 | TM68B | MTM001 | MTM68BMXT3X | 2005
T3x-06-G3-110 | TM94 | TM94B | 2006-2008
T3x-06-G3-220 | TM94 | 2006-2008
T3xi-06-G3-110 | TM94B | 2006-2008
T3xi-06-G3-220 | TM94B | 2006-2008
T3xi-08-G3 | TM504 | 2006-2008
T5-G1 | MTM65 | 2002-2004
T5x-02-G4 | FTM501 | CTM501 | 2009
T5x-05-G2 | MTM65C | 2005
T5x-06-G3-110 | TM65D | 2006-2008
T5x-06-G3-220 | TM65D | 2006-2008
U5x-02-G4 | CB75 | EP90 | 2009
MX-U5x / U5x-05-G2 | MCB32B | 2005
T1x-02-G4 | FTM507B | CTM507 | 2009-2010
T1xe-02-G4 | FTM507B | CTM510 | 2009-2010
T3xe-02-G4 | FTM509B | CTM510 | 2009-2010
T5x-04-G4 | FTM501C | CTM501C | 2009-2010
T7x-02-G4 | FTM501C | CTM502C | 2009-2010
T7xe-02-G4 | FTM501C | CTM503D | 2009-2010
T1X-03 | FTM507D | CTM507C | 2012
T7xe | FTM501E | CTM503F | CTM503G | 2012
T3x-03 | FTM509D | CTM509C | 2012
T1x-LS | 2012
T1xe | FTM507D | CTM510C | 2012
T3xe | FTM509D | CTM510C | 2012
T7xe-03 | FTM501E | CTM520 | CTM520B (VA) | 2013
220V T5x-07 | FTM501G | CTM519 | 2013
T5x-03-G4 | FTM501 | CTM501B | 2010
T5x-03-G4-220v | FTM501 | CTM501B | 2010
S3x-01-G4 | CS15 | 2009
U3x-01-G4 | CB86 | 2009
I5x-G3 | EP76 | REP76 | 2006-2008
A5x-07-G3 | EP72 | 2006-2008
T5x-05 | FTM501E | CTM501D | 2012
T7x | FTM501E | CTM502D | 2012
T5x-07 | FTM501E | CTM519 | 2013
220V T7xe-03 | FTM501G | CTM520 | CTM520B (VA) | 2013
T5x-07 | FTM501H | CTM519B | 2013
